High efficiency and improved safety

• ω (omega) Flows Construction
  The boilers using ω (omega) flows construction which consist of vertically - mounted water tubes sandwiched at the top and bottom between two annular headers. The effective heat transfer surface area is large due to the bigger combustion chamber and heat absorption from contact heat transfer is increased due to a faster combustion gas flow.

• New Structural Design
  The newly designed boiler construction and combustion gas flow help gain maximum heat transfer performance from a limited heat transfer area which less than 10m2. Effective usage is made by the entire heat transfer area, the result is 85% boiler efficiency (for EH-1000FS is 95%). Further, space saving is obtained by the compact design. (compare to previous version)

Higher fuel economy and longer service life

• Surface Blowdown
  One drawback that small once-through boilers areconsidered that the tendency for water to become concentrated more quickly compared to fire tube and water tube boilers because of their low water content. Accordingly, blowdown of concentrated water helps keep water concentration below a certain level and prevents alkaline corrosion of the water tube (EH-1000F & EH-1000FS).

• Low-Noise Burner
  Substantially improved burner combustion performance, Quiet operation and blower noise. The surrounding environment is not affected, allowing operation at all hours of the day or night.

Superior new design for ease of use

• Easy Operation, inspection and maintenance due to a simple structural design.
